TECHNICAL SPECIFICATIONS | PoliSAR T-100T |
|---|---|
| Turntable Diameter | 1650 mm |
| Turntable Speed | Max. 12 rpm |
| Wrapping Height | 2200 mm / 2750 mm / 3000 mm |
| Capacity | 15–20 pallets/hour |
| Pallet Dimensions (mm) | 800 × 1200 / 1000 × 1200 / 1200 × 1200 |
| Maximum Pallet Weight | 1200 kg / 1650 kg |
| Pre-Stretch Ratio | 200% Motorized Pre-Stretch System |
| Operating Voltage | 220 V – 50 Hz |
| Power Consumption | 1.3 kW |
| Machine Dimensions | 1650 mm × 2580 mm × 2380 mm |
| Machine Weight | 600 kg |
| Turntable Height | 85 mm |
| Control System | GMT E70 |
| Automatic Pallet Height Detection | Standard |
Our machines are equipped with a motorized pre-stretch system. Thanks to the 200% pre-stretch ratio, a 23-micron / 1500 m machine stretch film can be extended and used up to approximately 4000 meters. This results in significant film savings and reduced wrapping costs.
Via the operator control panel:
Within each recipe;
After the wrapping cycle is completed, the machine automatically returns to its home (start) position.
Additionally:
Manual turntable rotation and manual elevator up/down positioning features provide added convenience for the operator.
In terms of safety:
The machine is equipped with a total of 3 emergency stop buttons:
We will be pleased to assist you in selecting the most suitable model for special pallet sizes or alternative solutions.
Technical Support: After machine delivery and throughout its operational life, our technical service team will always be at your side. Installation and operator training are provided by our company.
